8M Aluminium Stage Truss SystemTriangular Gable Roof Trusses Stage Structure:
This 8 m Aluminium Stage Truss Gable Roof Truss Stage Structure is extended from Truss Box System 8x8 m . It is standard packages. It is modular and versatile. It is quick and easy to assemble, saving building time and labour cost.
Features:
- Just install the system with your standard ITSC-BS30 in stock
- Bolt connection makes less cost
- Coating power to be black is available
- Featuring with stage systems as ballast system and the box truss systems under the roof to hang more lighting
Specification:
Items | 8x8m Aluminium Stage Truss Triangular Roof System |
Towers | 300x300mm bolt truss |
Main grid | 300x300mm box truss |
Dimensions for the truss system | 8x8x6m |
Dimensions for the portable stage system | 7.32x7.32m |
Loading capacity for the truss system | Approx. 6464kg |
Loading capacity for the stage system | Approx.40186kg |
Self-weight for the truss system | Approx.1250kg |
Self-weight for the stage system | Approx. 1260kg |
Transportation volume for the truss system |
Approx. 12m3 |
Transportation volume for the stage system | Approx. 9m3 |
Max. wind speed | Approx. 28.4m/s |
Application:
- Theatre shows
- musicals and operas
- festivals and fairgrounds
- Exhibitioins and trade shows
- Celebrations
- Parties
- Conventions
- larg-scale meetings
- Studios
- Churches
- Wedding
- Sport clubs
- DJ events
- Roadshows
- Concerts
- TV
